120w Plug In Battery Charger Aa Battery Recharger Electronic Cigarette Battery Charger
| Certification |
| ISO14001, ISO9001, BSCI |
| SAA, RCM, C-TICK, CCC, BSMI, BIS, KC, KCC, PSE, ECA, CE, CB, UKCA, GS, UL, FCC |
| FEATURES | SAFETIES APPROVALS | PRODUCTS PICTURE |
| v EFFICIENCY VI v 100-120W OUTPUT POWER v OVERCURRENT PROTECTION v SHORT CIRCUIT PROTECTION v INPUT PROTECTION v ROHS COMPLIANT | Desktop Type v UL, FCC v CB, CE, UKCA v CCC, KC, PSE v SAA v REACH, ROHS |  |
| TYPICAL MODEL LIST |
| I/P Voltage | Typical model | Output Voltage | Output Current | Ripple & noise | Efficiency Level |
| 90 - 264V 47 - 63HZ | CGSW120D-120-10000 | 12V | 10000mA | 30mV | 6 Level VI |
| CGSW120D-150-8000 | 15V | 8000mA | 40mV | 6 Level VI |
| CGSW120D-180-6666 | 18V | 6666mA | 50mV | 6 Level VI |
| CGSW120D-200-6000 | 20V | 6000mA | 70mV | 6 Level VI |
| CGSW120D-360-3333 | 36V | 3333mA | 50mV | 6 Level VI |
| CGSW120D-480-2500 | 48V | 2500mA | 50mV | 6 Level VI |
| INPUT SPECIFICATIONS | GENERAL SPECIFICATIONS |
| Input Voltage | 90〜264VAC | Primary to Secondary | 50MΩ MIN |
| Input Frequency | 47〜63Hz | Efficiency | VI |
| Input Current | 1.5A Max | Standby Power | 0.5W MAX |
| Inrush Current | 40A Max | Leakage Current | 0.25mA MAX |
| OUTPUT SPECIFICATIONS | ENVIRONMENTAL SPECIFICATIONS |
| Output Voltage Range | 12.00V-48.00V | Operating Temperature | 10°C~40°C |
| Output Current Range | 100mA-10000mA | Cooling | Convection |
| Output Power Range | 120W Max | Temperature Coefficient | 0.05%/°C |
| Short Circuit Protection | Automatic Recovery | Humidity | 5~95%RH(non-condensing) |
| Over-Current Protection | Automatic Recovery | Storage Temperature | -20°C~+80%°C |
| Ripple and Noise | 100mVp-p max | PHYSICAL SPECIFICATIONS |
| Turn On Time | 20-30mS normal | Physical Specifications | 172.4mm *72.4mm *33.4mm |
| Line Regulation | 1% max | SAFETIES STANDARD |
| Output Regulation | ±5% | Safeties Standard | 62368 / 60950 / 60335 / 61558 / 60065 / UL1310 |
ABOUT Yingyuan:
Since 2006-----rich experience and professional in adapter field
As a leading manufacturer of AC adapter and transformer in Shenzhen, China, Yingyuan has been specialized
in power supply products for over 14 years.
Focusing on AC adapter marketing and manufacturing, Yingyuan has scientific, intact and efficient quality
management system, which extends from product designing, raw material control, on-spot production
management to after-sale services with constant, stable and reliable quality assurance.
ISO9001:2008 system is fully implemented in our management. Our products have passed most of safety
approvals in the world, including UL, cUL, FCC, PSE, GS, CE, SAA, CCC, C-tick, CB, etc.
Welcome to visit our company for further information!
Q: Are you a manufacturer?
A: Of course we are a famous manufacturer which in ShenZhen,China found in 2005.Welcome to visit our factory in any time.
Q: How about warranty?
A : We offer 3 years Warranty.
Q: How can I finish my payment?
A: T/T, L/C, Western Union are all acceptable, PayPal is also OK.
Q : what is the lead time ?
A : Samples are 3-5 days . Mass products Usurally 25-30 working days
Q: How about sample? For free?
A: YES! Generally we offer 1-3PCS sample(s) for your test FOR FREE, but you need to bear the freight cost. |
